Product Summary

The TLV5624IDRG4 is a lower power 8-bit digital-to-analog converter with internal reference and power down. Its applications include Digital Servo Control loops, digital offset and gain adjustament, industrial process control, machine and motion control devices, mass storage Devices. The resistor string output voltage is buffered by a x2 gain rail-to-rail output buffer. The programmable settling time of the DAC allows the designer to optimize speed vs power dissipation.

Parametrics

TLV5624IDRG4 absolute maximum ratings: (1)supply voltage: 7V; (2)reference input voltage range: -0.3 to VDD+0.3V; (3)Digital input voltage range: -0.3 to VDD+0.3V; (4)operating free-air temperature range: 0 to 70℃; (5)storage temperature range: -65 to 150℃; (6)lead temperature: 260℃.

Features

TLV5624IDRG4 features: (1)8-Bit Voltage Output DAC; (2)Programmable Internal Reference; (3)Compatible With TMS320 and SPI Serial Ports; (4)Differential Nonlinearity<0.2 LSB; (5)Monotonic Over Temperature.

Diagrams

TLV5624IDRG4 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
TLV5624IDRG4
TLV5624IDRG4
Texas Instruments
DAC (D/A Converters) 8-Bit 1.0-3.5us DAC Serial Out
Data Sheet
0-1850: $1.31
1850-2000: $1.27
2000-2500: $1.27
2500-5000: $1.21
