MBR40250G

MBR40250G, switchmode schottky power rectifier, 250V, 40A

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.50~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10000 :	0.50 / Piece

PartNumber:: MBR40250G

Brand:: ON Semiconductor - ON | Pack: TO | D/C: 11+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. qi's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-16

From Other Seller

Part Number:MBR40250G
US $0.50 - 0.50
Quantity:

piece

Product Summary

The MBR40250G is a 250 V, 40 A SWITCHMODE Schottky Power Rectifier. It has many benefits such as reduces or eliminates reverse recovery oscillations; minimizes need for EMI filtering; reduces switching losses; improved efficiency. The MBR40250G can be applied in power supply, power management, automotive, instrumentation.

Parametrics

MBR40250G absolute maximum ratings: (1)Peak Repetitive Reverse Voltage: 250V; (2)Average Rectified Forward Current: 40 A; (3)Peak Repetitive Forward Current: 80 A; (4)Nonrepetitive Peak Surge Current: 150 A; (5)Storage Temperature: -65 to +175°C; (6)Operating Junction Temperature: -65 to +150°C; (7)Voltage Rate of Change (Rated VR): 10,000 V/μs.

Features

MBR40250G features: (1)250 V Blocking Voltage; (2)Low Forward Voltage Drop, VF = 0.86 V; (3)Soft Recovery Characteristic, TRR < 35 ns; (4)Low Reverse Current, IR = 30μA; (5)Stable Switching Performance Over Temperature; (6)Pb-Free Packages are Available.
