Product Summary

The A3P125-TQG144 is a flash family FPGA with optional soft ARM support.

Parametrics

A3P125-TQG144 absolute maximum ratings: (1)DC core supply voltage: -0.3 to 1.65V; (2)JTAG DC voltage: -0.3 to 3.75V; (3)programming voltage: -0.3 to 3.75V; (4)analog power supply: -0.3 to 1.65V; (5)DC I/O output buffer supply voltage: -0.3 to 3.75V; (6)storage temperature: -65 to 150℃; (7)junction temperature: 125℃.

Features

A3P125-TQG144 features: (1)15 k to 1 M System Gates; (2)Up to 144 kbits of True Dual-Port SRAM; (3)Up to 300 User I/Os; (4)Core Voltage for Low Power; (5)Support for 1.5 V-Only Systems; (6)Low-Impedance Flash Switches.

Diagrams

A3P125-TQG144 DIAGRAM

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
A3P125-TQG144
A3P125-TQG144

IC FPGA 1024MAC 133I/O 144TQFP
Data Sheet
0-1: $11.22
1-10: $10.20
10-25: $9.44
25-100: $8.67
100-250: $7.91
250-500: $7.40
500-1000: $6.78
1000-2500: $6.50
2500-5000: $6.38
A3P125-TQG144I
A3P125-TQG144I

IC FPGA 1KB FLASH 125K 144-TQFP
Data Sheet
0-60: $13.36
