Product Summary

The PT6903 is a PFM high brightness LED driver control IC. It allows efficient operation of driver current up to 1.0A output, and the input range is from 7V to 36V. Moreover, PT6903 controls the internal MOS at a modulated switch frequency up to 800KHz. PT6903 drives a single or multiple series LEDs at a constant-current control method; thus, providing constant current light output and enhanced reliability. PT6903 integrates more protection functions. The reliability of LEDs and device can be promoted by these protection functions. PT6903 provides over current protection when output short-circuit or LEDs current rises up about two times setting current.

Parametrics

PT6903 absolute maximum ratings:(1)Wide input voltage range:7V to 36V;(2) Applications up to 1.0A.

Features

PT6903 features: (1)>90% efficiency; (2)Wide input voltage range: 7V to 36V; (3)Constant current driver; (4)Applications up to 1.0A; (5)Linear & PWM dimming; (6)Thermal shutdown protection; (7)Over current protection; (8)Internal 40V power NMOS switch.

Diagrams

PT6903 pin configuration
