Product Summary
The T835-600B is a 8A triac. Available either in through-hole or surface-mount packages, the T835-600B is suitable for general purpose AC switching. The T835-600B can be used as an ON/OFF function in applications such as static relays, heating regulation, induction motor starting circuits or for phase control operation in light dimmers, motor speed controllers. The T835-600B is specially recommended for use on inductive loads, thanks to their high commutation performances. By using an internal ceramic pad, the BTA series provides voltage insulated tab (rated at 2500V RMS) complying with UL standards.
Parametrics
T835-600B absolute maximum ratings: (1)IT(RMS), RMS on-state current (full sine wave): 8A; (2)ITSM, Non repetitive surge peak on-state current (full cycle, Tj initial = 25℃): 80 A; (3)I2t, I2t Value for fusing: 36 A2s; (4)dI/dt, Critical rate of rise of on-state current: 50 A/μs; (5)IGM, Peak gate current: 4 A; (6)PG(AV), Average gate power dissipation: 1 W; (7)Tstg, Storage junction temperature range: - 40 to + 150℃; (8)Tj, Operating junction temperature range: - 40 to + 125℃.
Features
T835-600B features: (1)IT(RMS): 8A; (2)VDRM/VRRM: 600 and 800 V; (3)IGT (Q1): 5 to 50 mA.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 T835-600B |
STMicroelectronics |
Triacs 8.0 Amp 600 Volt |
Data Sheet |
|
|
||||||||||||
|
T835-600B-TR |
STMicroelectronics |
Triacs 8.0 Amp 600 Volt |
Data Sheet |
|
|
||||||||||||
