Product Summary

The 25LC512-I is a 512 Kbit serial EEPROM memory with byte-level and page-level serial EEPROM functions. The 25LC512-I also features Page, Sector and Chip erase functions typically associated with Flash-based products. These functions are not required for byte or page write operations. The memory is accessed via a simple Serial Peripheral Interface (SPI) compatible serial bus.

Parametrics

25LC512-I absolute maximum ratings: (1)Vcc:6.5V; (2)All inputs and outputs w.r.t. Vss:-0.6V to Vcc+1.0V; (3)Storage temperature:-65°C to 150°C; (4)Ambient temperature under bias:-40°C to 125°C; (5)ESD protection on all pins:4 kV.

Features

25LC512-I features: (1)20 MHz max. Clock Speed; (2)Byte and Page-level Write Operations:- 128-byte page and - 5 ms max; (3)Low-Power CMOS Technology:- Max. Write Current: 5 mA at 5.5V, 20 MHz; (4)Electronic Signature for Device ID; (5)Sector Write Protection (16K byte/sector): - Protect none, 1/4, 1/2 or all of array; (6)Built-In Write Protection: - Power-on/off data protection circuitry; (7)High Reliability: - Endurance: 1 Million erase/write cycles; (8)Pb-free and RoHS Compliant.

Diagrams

25LC512-I block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
25LC512-I/MF
25LC512-I/MF
Microchip Technology
EEPROM 512k 64KX8 2.5V SER EE IND
Data Sheet
0-1: $1.46
1-10: $1.16
10-25: $1.12
25-100: $1.07
25LC512-I/P
25LC512-I/P
Microchip Technology
EEPROM 512k 64Kx8 2.5V SER EE IND
Data Sheet
0-1: $1.32
1-10: $1.06
10-25: $1.02
25-100: $0.98
25LC512-I/SN
25LC512-I/SN
Microchip Technology
EEPROM 512k 64Kx8 2.5V SER EE IND
Data Sheet
0-1: $1.28
1-10: $1.02
10-25: $0.98
25-100: $0.94
25LC512-I/SM
25LC512-I/SM
Microchip Technology
EEPROM 512k 64KX8 2.5V SER EE IND
Data Sheet
0-1: $1.29
1-10: $1.03
10-25: $1.00
25-100: $0.95
25LC512-I/S16K
25LC512-I/S16K
Microchip Technology
EEPROM 512k, 64K X 8 , 2.5V SER EE IND, DIE in WAFFLE PK
Data Sheet
Negotiable
25LC512-I/W16K
25LC512-I/W16K
Microchip Technology
EEPROM 512k, 64K X 8 , 2.5V SER EE IND, WAFER
Data Sheet
Negotiable
25LC512-I/WF16K
25LC512-I/WF16K
Microchip Technology
EEPROM 512k, 64K X 8 , 2.5V SER EE IND, WAFER on FR
Data Sheet
Negotiable
