Product Summary
The AP3602AKTTR-E1 is the regulated step-up DC/DC converter based on charge pump technique. The IC has the ability to supply 100mA constant output current or 250mA peak output current for 100ms from 3.0V to 5V input (2.7V to 4.5 V for AP3602B), so the AP3602AKTTR-E1 can be used as white LEDs driver or flash LED driver.
Parametrics
AP3602AKTTR-E1 absolute maximum ratings: (1)Input Voltage: 7V; (2)Output Voltage: 7V; (3)SHDN Pin Voltage: 7V; (4)Thermal Resistance (Junction to Ambient, no Heat sink): 300℃/W; (5)Operating Junction Temperature: 150℃; (6)Storage Temperature Range: -65 to 150℃; (7)Lead Temperature (Soldering, 10sec): 260 ℃; (8)ESD (Human Body Model): 2000 V.
Features
AP3602AKTTR-E1 features: (1)Low Quiescent Current: 13μA Typical; (2)Regulated Output Voltage Precision: 4%; (3)High Output Current: 100mA when VIN≥3.0V; 50mA when VIN≥2.7V; (4)High Frequency: up to 1.2 MHz; (5)Low Shutdown Supply Current: <1μA; (6)High Output Peak Current: 250mA for 100ms; (7)Over Temperature Protection; (8)Operating Temperature Range: -40 to 85℃.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 AP3602AKTTR-E1 |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
