AT24HC04BN-SH-T

AT24HC04BN-SH-T, Two-wire, Serial, EEPROM 4K (512 x 8), 5.0 mA, 6.25V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	3.00 / Piece

PartNumber:: AT24HC04BN-SH-T

Brand:: ATMEL Corporation - Atmel | Pack: SOP | D/C: 12+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. qi's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-04-19

From Other Seller

Part Number:AT24HC04BN-SH-T
US $3.00 - 3.00
Quantity:

piece

Product Summary

The AT24HC04BN-SH-T provides 4096 bits of serial electrically erasable and programmable read-only memory (EEPROM) organized as 512 words of 8 bits each. AT24HC04BN-SH-T is optimized for use in many industrial and commercial applications where low power and low-voltage operation are essential. The AT24HC04BN-SH-T is available in space-saving 8-lead PDIP, 8-lead JEDEC SOIC and 8-lead TSSOP packages and is accessed via a two-wire serial interface. In addition, the entire family is available in 1.8V (1.8V to 5.5V) version.

Parametrics

AT24HC04BN-SH-T absolute maximum ratings: (1)Operating Temperature: 40°C to +125°C; (2)Storage Temperature: 65°C to +150°C; (3)Voltage on Any Pin; (4)with Respect to Ground: 1.0V to +7.0V; (5)Maximum Operating Voltage:6.25V; (6)DC Output Current: 5.0 mA.

Features

AT24HC04BN-SH-T features: (1)Write Protect Pin for Hardware Data Protection ; (2)Low-voltage and Standard-voltage Operation; (3)Internally Organized 512 x 8 (4K); (4)Two-wire Serial Interface; (5)Schmitt Trigger, Filtered Inputs for Noise Suppression; (6)Bidirectional Data Transfer Protocol; (7)1 MHz (5V) and 400 kHz (1.8V, 2.5V, 2.7V) Clock Rate; (8)16-byte Page; (9)Partial Page Writes Allowed; (10)Self-timed Write Cycle (5 ms Max); (11)High Reliability; (12)8-lead PDIP, 8-lead JEDEC SOIC and 8-lead TSSOP Packages; (13)Die Sales: Wafer Form, Tape and Reel, and Bumped Wafers.
