Product Summary

Ideal for space critical applications, the LM4041CIM3-ADJ precision voltage reference is available in the sub-miniature SC70 and SOT-23 surface-mount packages. The LM4041CIM3-ADJ’s advanced design eliminates the need for an external stabilizing capacitor while ensuring stability with any capacitive load, thus making the LM4041CIM3-ADJ easy to use. Further reducing design effort is the availability of a fixed (1.225V) and adjustable reverse breakdown voltage. The minimum operating current is 60 µA for the LM4041CIM3-ADJ. The applications of the device include Portable, Battery-Powered Equipment, Data Acquisition Systems, Instrumentation, Process Control, Energy Management, Automotive, Precision Audio Components.

Parametrics

LM4041CIM3-ADJ absolute maximum ratings: (1)Reverse Current: 20 mA; (2)Forward Current: 10 mA; (3)Maximum Output Voltage: 15V; (4)Power Dissipation: 306 mW; (5)Storage Temperature: -65 to +150℃; (6)Lead Temperature: +215℃; (7)ESD Susceptibility: Human Body Model: 2 kV; Machine Model: 200V.

Features

LM4041CIM3-ADJ features: (1)Small packages: SOT-23, TO-92, and SC70; (2)No output capacitor required; (3)Tolerates capacitive loads; (4)Reverse breakdown voltage options of 1.225V and adjustable.

Diagrams

LM4041CIM3-ADJ functional block diagram
