REF2940AIDBZT

REF2940AIDBZT, 100ppm/C, 50UA in SOT23-3, 7.0V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.20~1.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100000 :	1.20 / Piece

PartNumber:: REF2940AIDBZT

Brand:: Texas Instruments - TI | Pack: SOT | D/C: 12+

Availability:: Supply Ability: 100000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. qi's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-04-21

From Other Seller

Part Number:REF2940AIDBZT
US $1.20 - 1.20
Quantity:

piece

Product Summary

The REF2940AIDBZT is a precision, low-power, low-voltage dropout voltage reference family available in a tiny SOT23-3. The REF2940AIDBZT small size and low power consumption (50μA max) make it ideal for portable and battery-powered applications. The REF2940AIDBZT does not require a load capacitor, but is stable with any capacitive load. Unloaded, the REF2940AIDBZT can be operated with supplies within 1mV of output voltage. All models are specified for the wide temperature range, –40°C to +125°C.

Parametrics

REF2940AIDBZT absolute maximum ratings: (1)Supply Voltage: 7.0V; (2)Output Short-Circuit: Continuous; (3)Operating Temperature: –40°C to +125°C; (4)Storage Temperature: –65°C to +125°C; (5)Junction Temperature: +150°C; (6)Lead Temperature (soldering, 10s): +300°C.

Features

REF2940AIDBZT features: (1)MicroSIZE PACKAGE: SOT23-3; (2)LOW DROPOUT: 1mV; (3)HIGH OUTPUT CURRENT: 25mA; (4)LOW TEMPERATURE DRIFT: 100ppm/°C max; (5)HIGH ACCURACY: 2%; (6)LOW IQ: 50μA max.
