SST39VF800A-70-4I-EKE

SST39VF800A-70-4I-EKE, 2 Mbit, 4 Mbit, 50 mA, -2.0V to VDD+2.0V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.20~1.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	1.20 / Piece

PartNumber:: SST39VF800A-70-4I-EKE

Brand:: Silicon Storage Technology, Inc - SST | Pack: BGA | D/C: 09+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. qi's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-04-21

From Other Seller

Part Number:SST39VF800A-70-4I-EKE
US $1.20 - 1.20
Quantity:

piece

Product Summary

The SST39VF800A-70-4I-EKE devices are 128K x16 / 256K x16 / 512K x16 CMOS Multi-Purpose Flash (MPF)manufactured with SST proprietary, high-performance CMOS SuperFlash technology. The split-gate cell design and thick oxide tunneling injector attain better reliability and manufacturability compared with alternate approaches. The SST39VF800A-70-4I-EKE write (Program or Erase) with a 3.0-3.6V power supply. The SST39VF800A-70-4I-EKE write (Program or Erase) with a 2.7-3.6V power supply. These devices conform to JEDEC standard pinouts for x16 memories.

Parametrics

SST39VF800A-70-4I-EKE absolute maximum ratings: (1)Temperature Under Bias: -55°C to +125°C; (2)Storage Temperature: -65°C to +150°C; (3)D. C. Voltage on Any Pin to Ground Potential: -0.5V to VDD+0.5V; (4)Transient Voltage (<20 ns) on Any Pin to Ground Potential: -2.0V to VDD+2.0V; (5)Package Power Dissipation Capability (TA = 25°C): 1.0W; (6)Surface Mount Solder Reflow Temperature: 260°C for 10 seconds; (7)Output Short Circuit Current: 50 mA.

Features

SST39VF800A-70-4I-EKE features: (1)Organized as 128K x16 / 256K x16 / 512K x16; (2)Single Voltage Read and Write Operations; (3)Superior Reliability; (4)Low Power Consumption; (5)Sector-Erase Capability; (6)Block-Erase Capability; (7)Fast Read Access Time; (8)Latched Address and Data; (9)Fast Erase and Word-Program; (10)Automatic Write Timing; (11)CMOS I/O Compatibility; (12)JEDEC Standard.
